GB Series CNC Hydraulic Bending Machine

GB Series is a fine precision and high-efficiency plate bending processing equipment with 55 to 240 tons available tonnage capacities

  • Easy to Operate
  • High Precision
  • Stable Performance
  • Energy Saving
Model Nominal force﹙KN﹚ Distance among columns(mm) Length of workbench(mm) Throat depth(mm) Slider’s trip(mm)



Maximum height(mm) Main motor(kW) Weight(kg) Overall Dimensions
GB-10032 1000 2700 3200 400 200 460 7.5 8300 3400*1990*2580
GB-16032 1600 2700 3200 400 200 460 11 10000 3400*2035*2700
GB-16041 1600 3600 4100 400 200 460 11 11500 4300*2035*2700
GB-20032 2000 2700 3200 400 240 500 15 12000 3400*2165*2810
GB-20041 2000 3600 4100 400 240 500 15 13500 4300*2165*2810
GB-25032 2500 2700 3200 400 240 500 15 13000 3400*2175*2865
GB-25041 2500 3600 4100 400 240 500 15 14500 4300*2175*2865
GB-40041 4000 3300 4100 430 240 530 30 23000 4300*2335*3420
bending sample
Bending Sample A
bending sample
Bending Sample B
bending sample
Bending Sample C
bending sample
Bending Sample D
Easy to Operate

Easy to Operate

Adopt Italian ESA professional CNC system with powerful functions and simple operation

High Precision

Equipped with an Italian GIVI grating ruler, supporting high precision bending, the resolution can reach 0.005mm.

High Precision Bending
Stable Performance

Stable Performance

Adopt German BoschRexroth professional hydraulic system with high response frequency and stable performance.

Energy Saving

Optional high-performance servo motor, real-time control of motor speed, reduce oil pump work, oil temperature and noise, and save more than 50% of energy

Energy Saving
